Loyalsuns coffee vending machine MR1-14B-A
√ Visual coffee bean hopper
√ Pick up
√ Heavy duty adjustable casters
√ 32-inch touch selection screen
√ Card reader installation
√ Visual rotating cup carrier
- Overview
- Recommended Products
| Model | MR1-14B-A |
| Dimension | H1950mm × W1060mm × D805mm |
| Panel Material | 4mm Ultra white tempered glass |
| Weight | 325kg |
| Casters | 360° Rotation, height adjustable (single bearing 500KG) |
| Operating environment | 5-35 ℃ |
| Power supply specifications | 220-240V~ 50/60Hz 16A |
| Maximum power | 3500W |
| Standby power | ＜100W |
| Screens | 1 |
| Screen size | 32-inch touch vertical screen (for production selection) |
| Networking methods | 1 |
| Payment methods | WeChat/Alipay/card reader/cash/third-party interface |
| Cleaning methods | Standard cleaning/regular cleaning/descaling cleaning |
| Pick-up door | Transparent lifting door (double anti pinch protection) |
| Cup carrying method | Visual linear motion cup carrier |
| Door lock | Electronic lock + mechanical lock |
| Water supply | 18L purified water barrel × 3 (including direct drinking water interface) |
| Heating | 2700W High pressure resistant heat storage boiler |
| Paper cup dropper | 1 |
| Paper cup storage | 3 tubes（around 150 cups） |
| Paper cup specifications | Diameter 90mm, 16 ounces |
| Plastic cup dropper | 4G/WIFI/RJ45 network cable |
| Plastic cup storage | 3 tubes（around 150 cups） |
| Plastic cup specifications | Diameter 90mm, 16 ounces |
| Pulp boxes | 2 or 4 |
| Powder boxes | 6 |
| Brewing parameters | 1*16g 9-16bar |
| Coffee bean box | 1（Visual coffee bean box） |
| Ice maker | Ice making capacity: 120Kg/day |
30+ A drink to satisfy your taste
Drink formula can be adjusted according to demand
Hot Drinks
Espresso, Americano, Latte, Cappuccino, chocolate milk, Warm milk, fancy milk tea...
Ice Drink
Iced Espresso, Iced Americano, Iced Latte, Iced Cappuccino, Iced Milk Tea, Iced Juice....
Brewer Modul：
1. Large-capacity extraction chamber, 12-28g per shot
2. The structure is easy to disassemble and take out from the machine
Fully waterproof construction for easy maintenance
3. The combination of metal and high-strength plastic, long life
Ice Maker Mod：
1. 120kg/day ice-making speed to ensure continuous sales of ice drinks
2. Accurate and quantitative ice production to ensure product consistency
3. Ice cubes are hard and transparent, melting more slowly
4. It can work stably for a long time in harsh environments
5. R290 refrigerant, high efficiency and environmental protection
SMB
The unique core technologies of our company
SMB is a system that enables personalized setting of coffee extraction status through multi-dimensional parameterization.
The system consists of hardware modules and a software control system.
Through this system, the extraction rate, crema, acidity, etc. of the coffee extract can be adjusted, thereby altering the flavor of the coffee liquid.
A professional barista can definitely make a coffee that he considers satisfactory through the SMB system.
Machine management platform
Cooperative merchants
Our products can be used in public administration, large supermarkets, libraries, restaurants, hospitals, companies, rest facilities, colleges and other scenarios.
